Our range of copper hot water cylinders provides an efficient and reliable solution for domestic hot water storage in Irish homes.
These have been developed to help reduce your home heating bill by ensuring optimum efficiency and therefore reducing energy use and costs.
Our copper cylinders include optimal insulation.
Available in a wide range of sizes, with both single coil and dual coil options, our copper cylinders are designed to deliver dependable hot water while helping to improve heating efficiency and reduce energy consumption.
A typical house uses nearly 50% of its energy consumption on hot water production.
High-quality insulation helps minimise heat loss, while advanced heat exchanger technology allows the cylinder to reheat efficiently when paired with correctly sized boiler and pipework.
Reducing the heat up time of the hot water cylinder improves its efficiency by significantly reducing the amount of heat that the cylinder losses on an average day saving you money.
The range also incorporates a unique cold feed diffuser, designed to reduce turbulence and mixing inside the cylinder, helping maintain hot water at the top of the cylinder and potentially improving overall cylinder efficiency.
This reduces mixing and keeps hot water hotter.
With different capacities and configurations available, you can select a copper cylinder to suit your household size, hot water requirements and heating system.
This further helps to reduce heat loss and therefore reducing energy consumption on your boiler.
With regard to tappings in the dome these come as standard in the indirect cylinders but not as standard in the dual coil cylinders.
You can choose to also install an immersion heater and you can see the options for that here.
What is a single coil hot water cylinder?
A single coil hot water cylinder is the most common found in Irish homes and takes water from one source and heats the water in the cylinder.
The main heat sources in Ireland would be a oil or gas fired boiler.
If the boiler is not firing or is turned off then the water can still be heated if there is an immersion heater in place.
What is a dual coil hot water cylinder?
A dual could hot water cylinder is sometimes also known as a twin coil hot water cylinder and this is used when two methods of heating the water are used.
The most common instance of this in Ireland would be the use of solar panels to heat the water using the lower coil in the cylinder and the gas or oil boiler heating the water via the upper coil.
What can happen with the use of solar panels in Ireland is that on a gloomy or dull day then the solar panels might only heat a small proportion of the water that is needed.
When this happens then the gas or oil boiler will supplement that by heating the water via the upper coil.
Normally the lower coil is the one that has the first chance to heat the water and the upper coil will only be used if the water is not heated to the desired temperature.
A wood burning stove can also be used to heat the lower coil.
Do you also need pipe fittings?
The most common pipe fittings used with these cylinders are Compression 312 and Compression 317 brass pipe fittings.
The typical sizes utilised are 1" x 3/4" and 1" x 1".
We have a vast range of pipe fittings available so if you have any questions about these you can call us on 0818 888 000 and we will help in every way needed.
Warranty information:
These have a one year manufacturer warranty.
If the size you are looking for is not listed please contact My Building Supplies on 0818 888 000.
Capacity:
LB Cylinders 30" x 18" Insulated Copper Hot Water Cylinder
- Capacity:95 litres
You can see the Product Data Sheet for this model here
LB Cylinders 36" x 15" Insulated Copper Hot Water Cylinder
- Capacity:94 litres
LB Cylinders 36" x 18" Insulated Copper Hot Water Cylinder
You can see the technical drawing and specification info on this model here
LB Cylinders 42" x 15" Insulated Copper Hot Water Cylinder
- Capacity:114 litres
LB Cylinders 42" x 18" Insulated Copper Hot Water Cylinder
- Capacity:140 litres
You can see product information sheet for this model here
LB Cylinders 48" x 15" Insulated Copper Hot Water Cylinder
- Capacity:133 litres
LB Cylinders 48" x 18" Insulated Copper Hot Water Cylinder
- Capacity:162 litres
LB Cylinders 54" x 18" Insulated Copper Hot Water Cylinder
- Capacity:190 litres
LB Cylinders 60" x 18" Insulated Copper Hot Water Cylinder
- Capacity:205 litres
FAQs
What size copper cylinder do I need?
The appropriate cylinder capacity depends on household size, bathing and showering habits, hot water demand and the available installation space. A professional heating or plumbing installer can help determine the right capacity for your home's specific requirements.
What is the difference between a single coil and dual coil cylinder?
A single coil cylinder has one internal heat exchanger, typically connected to a boiler. A dual coil cylinder has two coils, allowing hot water to be heated from two separate heat sources, such as a boiler and a solar thermal system.
Why is insulation important in a copper cylinder?
Good-quality insulation helps reduce heat loss from stored hot water. This allows the water to remain hot for longer and can reduce the energy required to maintain the cylinder at its operating temperature.
What is the purpose of the cold feed diffuser?
A cold feed diffuser is designed to introduce incoming cold water gently into the cylinder, helping reduce mixing between hot and cold water. This helps maintain temperature stratification and keeps hotter water available towards the top of the cylinder.
Do copper cylinders come with dome tappings?
Dome tappings are supplied as standard on the indirect cylinders in this range. They are not supplied as standard on the dual coil cylinders, so the specific cylinder configuration and required connections should be checked before ordering.
